Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
On / uint32Selects a source that enables/disables process PID control.
See also parameter 40.7 Set 1 PID operation mode.
0 = Process PID control disabled.
1 = Process PID control enabled.
Set 1 PID activation
source
40.60
00.Off
11.On
2Process PID control is disabled when external control
location
EXT1 is active, and enabled when external control location
EXT2 is active.
See also parameter 19.11 Ext1/Ext2 selection.
Follow Ext1/Ext2
selection
3
Digital input DI1 (10.2 DI delayed status, bit 0).
DI1
4
Digital input DI2 (10.2 DI delayed status, bit 1).
DI2
5
Digital input DI3 (10.2 DI delayed status, bit 2).
DI3
6
Digital input DI4 (10.2 DI delayed status, bit 3).
DI4
7
Digital input DI5 (10.2 DI delayed status, bit 4).
DI5
8
Digital input DI6 (10.2 DI delayed status, bit 5).
DI6
11
Digital input/output DIO1 (11.2 DIO delayed status, bit 0).
DIO1
12
Digital input/output DIO2 (11.2 DIO delayed status, bit 1).
DIO2
See Terms and abbreviations (page 132).
Other [bit]
0.00 / real32Storage parameter for receiving a process feedback value
eg. through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data.
Set the target selection parameter of that particular data
(58.101…58.124) to Feedback data storage. In 40.8 Set
1 feedback 1 source (or 40.9 Set 1 feedback 2 source),
select Feedback data storage.
Feedback data
storage
40.91
100 = 1 / 100 = 1Storage parameter for process feedback.-327.68 ... 327.67
0.00 / real32Storage parameter for receiving a process setpoint value
eg. through the embedded fieldbus interface.
The value can be sent to the drive as Modbus I/O data.
Set the target selection parameter of that particular data
(58.101…58.124) to Setpoint data storage. In 40.16 Set 1
setpoint 1 source (or 40.17 Set 1 setpoint 2 source), select
Setpoint data storage.
Setpoint data storage40.92
100 = 1 / 100 = 1Storage parameter for process setpoint.-327.68 ... 327.67
