Def / Type
FbEq 16b / 32b
DescriptionName / Range /
Selection
No.
- / int32Data storage parameter 10.DataStorage 2 int3247.12
- / -32-bit integer.-2147483648...2147483647
- / int32Data storage parameter 11.DataStorage 3 int3247.13
- / -32-bit integer.-2147483648...2147483647
- / int32Data storage parameter 12.DataStorage 4 int3247.14
- / -32-bit integer.-2147483648...2147483647
- / int32Data storage parameter 13.DataStorage 5 int3247.15
- / -32-bit integer.-2147483648...2147483647
- / int32Data storage parameter 14.DataStorage 6 int3247.16
- / -32-bit integer-2147483648...2147483647
- / int32Data storage parameter 15.DataStorage 7 int3247.17
- / -32-bit integer.-2147483648...2147483647
- / int32Data storage parameter 16.DataStorage 8 int3247.18
- / -32-bit integer.-2147483648...2147483647
- / int16Data storage parameter 17.DataStorage 1 int1647.21
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 18.DataStorage 2 int1647.22
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 19.DataStorage 3 int1647.23
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 20.DataStorage 4 int1647.24
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 21.DataStorage 5 int1647.25
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 22.DataStorage 6 int1647.26
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 23.DataStorage 7 int1647.27
1 = 1 / 1 = 116-bit integer.-32768...32767
- / int16Data storage parameter 24.DataStorage 8 int1647.28
1 = 1 / 1 = 116-bit integer.-32768...32767
Unscaled / uint16
Defines the scaling of parameter 47.1 DataStorage 1 real32
to and from 16-bit integer format. This scaling is used when
the data storage parameter is the target of received 16-bit
data (defined in parameter group 62 D2D and DDCS
receive data), or when the data storage parameter is the
source of transmitted 16-bit data (defined in parameter
group 61 D2D and DDCS transmit data).
The setting also defines the visible range of the storage
parameter.
DataStorage 1 real32
type
47.31
0Data storage only. Range: -2147483.264 … 2147473.264.Unscaled
