What to doCause
Event name /
Aux. code
Code
(hex)
Check DC fuses.
Check converter module connections to
DC link.
DC link voltage difference detected by
the branching unit.
BU DC link
difference
AE0C
Check AC fuses.
Check supply cable.
Main voltage difference detected by the
branching unit.
BU voltage
difference
AE0D
Check ambient conditions.
Check air flow and fan operation.
Check heatsink fins for dust pick-up.
Check motor power against IGBT supply
unit power.
Power unit module temperature is
excessive.
Excess
temperature
AE14
Check the cabling.
Check cooling of power module(s).
High temperature difference between the
IGBTs of different phases.
Excess
temperature
difference
AE15
Check ambient conditions.
Check air flow and fan operation.
Check heatsink fins for dust pick-up.
Check motor power against IGBT supply
unit power.
IGBT temperature is excessive.IGBT
temperature
AE16
Define the supply voltage range
(parameter 95.1 Supply voltage).
The supply voltage range has not been
defined.
Voltage
category
unselected
AE24
Check that it is safe to continue
operation.
Return emergency stop push button to
normal position.
Restart the drive.
Supply unit has received an emergency
stop (mode selection off2) command.
Emergency
stop (OFF2)
AE58
Check module cooling air flow and fan
operation.
Check ambient temperature. If it exceeds
40 °C (104 °F), ensure that load current
does not exceed derated load capacity.
See appropriate hardware manual.
Check inside of cabinet and heatsink of
supply module for dust pick-up. Clean
whenever necessary.
Supply module temperature is excessive
due to eg, module overload or fan failure.
Temperature
Warning
AE5F
Check the auxiliary code in the line-side
converter program to identify the fan.
Check fan operation and connection.
Replace fan if faulty.
Cooling fan is stuck or disconnected.FanAE73
Resynchronize the IGBT supply unit to
the grid after net lost.
Net lost is detected.Net lostAE78
Two attempts in five minutes is allowed
to prevent charging circuit overheating.
There are too many DC link charging
attempts.
Charging countAE85
Fault tracing 583
