ABB CL Series User Manual

Wiring with the display system
126
1SVC 440 795 M1100
Table 9: Composition of the markers
Applies
to MD,
MW, MB,
M
Left = Most
significant bit,
byte, word
Right = Least
significant bit,
byte, word
32 bit MD1
16 bit MW2 MW1
8 bit MB4 MB3 MB2 MB1
1 bit M32 to M25 M24 to M17 M16 to M9 M8 to M1
32 bit MD2
16 bit MW4 MW3
8 bit MB8 MB7 MB6 MB5
1 bit M64 to M57 M56 to M49 M48 to M41 M40 to M33
32 bit MD3
16 bit MW6 MW5
8 bit
MB12 MB11 MB10 MB9
1 bit M96 to M89 M88 to M81 M80 to M73 M72 to M65
32 bit MD4
16 bit MW8 MW7
8 bit MB16 MB15 MB14 MB13
32 bit MD5
16 bit MW10 MW9
8 bit MB20 MB19 MB18 MB17
…
…
…
32 bit MD23
16 bit MW46 MW45
8 bit
MB92 MB91 MB90 MB89
32 bit MD24
16 bit MW48 MW47

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
