ABB CL Series User Manual

Wiring with the display system
184
1SVC 440 795 M1100
Function of the counter function block
Figure: 100: Signal diagram of counter
1: Counter coil C..C_
2: Upper setpoint value
>SH
3: Preset actual value >SV
4: Lower setpoint value >SL
5: Counting direction, coil C..D_
6: Accept preset actual value, coil C..SE
1
2
......... .........
3
4
6
7
8
9
10
11
12
ABCD E F
5

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
