ABB CL Series User Manual

CL-NET network, COM-LINK
serial connection
334
1SVC 440 795 M1100
Introduction to COM-LINK The COM-LINK is a point-to-point connection via a serial
interface. This interface connection allows the reading of
input/output states as well as the reading and writing of
marker ranges. This data can be used for setpoint entry or for
display functions. The stations of the COM-LINK have
different functions. The active station controls the entire
interface. The remote station responds to the requests of the
active station. The remote station cannot detect whether the
COM-LINK is active or whether a PC with CL-SOFT is using
the interface.
h
The two devices must support the COM-LINK.
h
Only the display system can be active station with
COM-LINK.
The remote station can be another display system.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
