ABB CL Series User Manual

Wiring with the display system
228
1SVC 440 795 M1100
Example 1:
The source range is a 10-bit value, source is the analog input
IA01.
The target range has 12 bits.
Parameter display and parameter set for the LS01 function
block:
The actual value at the analog input IA01 is 511.
The scaled output value is 2045.
Example 2:
The source range has 12 bits.
The target range has 16 signed bits.
>I1 = DC01QV
>X1 = 0
>X2 = 4095
>Y1 = –32768
>Y2 = +32767
The actual value at the analog input DC01QV is 1789.
The scaled output value is –4137.
Jumps
Jumps can be used to optimise the structure of a circuit
diagram or to implement the function of a selector switch.
Jumps can be used for example to select whether manual/
automatic operation or other machine programs are to be set.
Jumps consist of a jump location and a jump destination
(label).
LS01 +
>I1 IA01
>X1 0
>Y1 0
>X2 1023
>Y2 4095
QV>
