Creating your first
circuit diagram
85
1SVC 440 795 M1100
From the first contact to the output coil
With the display system you work from the input to the
output. The first input contact is
I 01.
X Press OK.
The display system proposes the first contact
I01 at the
cursor position.
I flashes and can be changed, for example, to a P for a
pushbutton input using the cursor buttons
Í or Ú.
However, nothing needs to be changed at this point.
X Press OK 2 ×, to move the cursor across the 01 to the
second contact field.
You could also move the cursor to the next contact field
using the
Í cursor button.
X Press OK.
Again, the display system inserts a contact
I 01 at the
cursor position. Change the contact number to
I 02, so
that N/C contact S2 can be connected to input terminal I2.
X Press OK so that the cursor jumps to the next position and
press cursor button
Í or Ú to change the number to 02.
X Press OK to move the cursor to the third contact field.
You do not need a third relay contact, so you can now wire
the contacts directly up to the coil field.
I 01
L: 1 C:1 B:7944
I 01 Ê
L: 1 C:1 B:7944
I 01 I 02
L: 1 C:2 B:7944
h
Press DEL to delete a contact at the cursor position.
-I 02 Ê
L: 1 C:3 B:7944
