Visualization with the
display system
276
1SVC 440 795 M1100
Standard path: C:\Program files\CL-SOFT\Samples\
Program:
StaticText_Prog_03.e60
Screen 1
Screen 1 shows a static text in normal font size.
Screen 2
Screen 2 shows a static text enlarged.
Screen 3
Screen 3 shows three static texts in different font sizes.
Screen 4
Screen 4 shows four static texts arranged vertically.
Bit display
The Bit display element has an input that can be associated
to a Boolean variable. The signal status of these variables
changes the display of the Bit display screen element in the
display system from a full screen to a frame display.
Programming in CL-SOFT
X Drag the Bit display element onto the screen with the left
mouse button depressed.
X Position the cursor over the element and move it to the
required position whilst holding down the mouse button.
The height and width of the element frame can be scaled as
required and is adjusted accordingly by enlarging or
reducing the screen element frame horizontally or
diagonally. This is done by dragging the selection square of
the element frame with the mouse button depressed.
“Associated Variable” tab: Definition of the Boolean
variable for controlling the bit display.
“Visibility” tab: Possibility to make the element invisible via
an associated variable.
