Connecting the CL-NET
network
71
1SVC 440 795 M1100
Calculating length with known cable cross-section
The maximum cable lengths are calculated for a known
conductor cross-section
l
max
= Cable length in m
S = Cable cross-section in mm
2
r
cu
= Resistivity of copper, if not otherwise stated 0.018 Omm
2
/m
Plugging and unplugging network cables
The display base module is provided with two RJ45 network
sockets.
The socket 1 in the first station is for the bus terminating
resistor. For other stations, socket 1 is used for plugging in
the incoming cable. Socket 2 is used for the outgoing cable
or for the bus termination resistor on the last physical station
in the network.
l
max
=
S × 12.4
r
cu
