Configuration of the
CL-NET network
325
1SVC 440 795 M1100
Configuration of the
CL-NET network
CL-NET can be configured so that it can be optimised for
your application.
Station number
The station number is identified as the NET-ID in the device.
The station number can be set on devices with a display
using the buttons on the display system.
Valid station numbers for operation are 01 to 08.
Station number 00 = Factory default setting
With station number 00, double address assignment cannot
occur when an existing device is being exchanged.
Transmission speed
The display system hardware allows you to set transmission
speeds between 10 and 1000 KBaud in specific stages. The
length of all cables determines the maximum permissible
data transfer rate (a chapter „Technical data“, page 408).
The data transfer rate is set under the BAUDRATE menu item.
Possible baud rates are: 10, 20, 50, 125, 250, 500 and 1000 KB
125 KB = Factory default setting
h
All CL-NET settings are best carried out on station 1. The
entire network can be configured from station 1. A local
configuration is only required when a device is exchanged.
