Memory requirement
413
1SVC 440 795 M1100
Function block outputs (operands)
Other operands
Memory requirement The following table serves as an overview of the memory
requirement of the display base module for rungs, function
blocks and their associated constants:
Input Meaning of abbreviation Description
QV Output value Output value
Other operands Description
MB Marker byte (8-bit value)
IA
Analog input (if present on the device!)
MW Marker word (16-bit value)
QA Analog output (if present on the device!)
MD Marker double word (32-bit value)
NU Constant (number), value range from
–2147483648 to +2147483647
Space requirement per rung/
function block
Space requirement per constant
at function block input
Byte Byte
Rung 20 –
Function blocks
A 68 4
AR 40 4
BC 48 4
BT 48 4
BV 40 4
C
52 4
