ABB CL Series User Manual

Configuration of the
CL-NET network
329
1SVC 440 795 M1100
The standard settings for the input and output devices are:
Station number (NET-ID) and baud rate can be specified via
station 1.
Station message types
The CL-NET network recognises various message types.
They are:
• Output data of station 1 (Q., S.) which is sent to stations
without programs.
• Send and receive network outputs and inputs between
stations with the program (*SN, *RN).
• Send and receive data between stations with the program
(PT and GT function blocks).
• Transfers of inputs, outputs, station status (I, R, Q, S).
• Load programs to and from every station.
The CL-NET network is based on a CAN (Controller Area
Network) system. Each message type has its own ID. The
message priority is determined via the respective ID. This is
important in transmission borderline cases to ensure that all
messages reach their destination.
SEND IO å
REMOTE RUN å
REMOTE IO å

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
