ABB CL Series User Manual

Wiring with the display system
186
1SVC 440 795 M1100
High-speed counters
The display system provides various high-speed counter
functions. These counter function blocks are coupled directly
to digital inputs. The high-speed counter functions are only
available with DC display I/O module.
The following functions are possible:
• Frequency counters, measure frequencies CF..
• High-speed counters, count high-speed signals CH..
• Incremental counter, count dual-channel incremental
encoder signals CI..
The high-speed digital inputs are I1 to I4.
The following wiring rules apply:
• I1: CF01 or CH01 or CI01
• I2: CF02 or CH02 or CI01
• I3: CF03 or CH03 or CI02
• I4: CF04 or CH04 or CI02
Example:
• I1: High-speed counter CH01
• I2: Frequency counter CF02
• I3: Incremental encoder channel A CI02
• I4: Incremental encoder channel B CI02
Caution!
Each digital input I .. may only be used once by the CF, CH,
CI function blocks.
The incremental encoder requires an input pair.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
