CL-NET network, COM-LINK
serial connection
338
1SVC 440 795 M1100
The normal rules for addressing the markers apply.
Configuration of the COM-LINK
For the COM-LINK connection to be functional, the following
settings must be known to the active station:
• Baud rate,
•COM-LINK (active)
• Remote marker range (data exchange range).
COM-LINK baud rate
The baud rate can be 9600 baud or 19200 baud.
h
Ensure a clear separation of the write range of the two
stations. The active station should write different markers
to the remote station. Otherwise the markers in the last
write operation will be overwritten.
BAUD RATE:19200B
COM-LINK
REMOTE MARKER...
h
In normal applications, select the higher baud rate of
19200 baud. The baud rate of 9600 baud should only be
selected if the connection is frequently faulty.
Factory setting: 9600 baud
