Introduction to COM-LINK
339
1SVC 440 795 M1100
Activating COM-LINK
The COM-LINK connection must be activated in order for it
to function.
Factory setting: Not active
The tick on the COM-LINK means that the COM-LINK
connection is active.
Remote markers, COM-LINK data exchange range
Select the REMOTE MARKER… menu option. Here you can
determine, select and modify the data exchange range.
In the example the READ range was selected with the marker
double words MD11 to MD15.
The WRITE range consists of the marker double words MD16
to MD18.
The entire data exchange range available is the marker
range MD01 to MD20 of the remote station. The active
station addresses these markers with 1MD*. The * indicates
the number of the marker concerned.
The smallest possible unit for defining a marker range is an
MD marker double word.
Example:
The read range of the active station is 1MD02.
The write range of the active station is 1MD03.
The read range of the remote station is thus MD03.
The write range of the remote station is MD02.
BAUD RATE:19200B
COM-LINK å
REMOTE MARKER...
h
The REMOTE MARKER… menu only opens if a tick is
displayed next to COM-LINK.
READ:
1MD11 Ç 1MD015
WRITE:
1MD16 Ç 1MD18
