ABB CL Series User Manual

Appendix
408
1SVC 440 795 M1100
CL-NET network
Resolution, analog V DC 0.01
Resolution, digital Bit 10
Value 0 to 1023
Recovery time μs 100
Accuracy (–25 to 55 °C), related to the range % 2
Accuracy (25 °C), related to the range % 1
Conversion time Each display base
module cycle
CL-LDR.17DC2,
CL-LDT.17DC2
CL-LDC.LNDC2
Number of stations 8
Bus length/transmission speed
1)
m/Kbaud 6/1000
25/500
40/250
125/125
300/50
700/20
1000/10
Electrical isolation
Yes
To power supply, inputs, outputs, CL-LINK,
PC interface, memory module
Bus termination (a accessories) Yes
First and last station
Plug connector (a accessories) poles 8
Type RJ45

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
