ABB CL Series User Manual

Appendix
404
1SVC 440 795 M1100
UL/CSA
Transistor outputs
Uninterrupted current at 240 V AC/24 V DC A 10/8
AC Control circuit rating codes (utilization category) B300 Light Pilot Duty
Max. rated operational voltage V AC 300
Max. thermal uninterrupted current cos v = 1 at B300 A 5
Maximum make/break capacity cos v k 1 (make/break)
at B300
VA 3600/360
DC Control circuit rating codes (utilization category) R300 Light Pilot Duty
Max. rated operational voltage V DC 300
Max. thermal uninterrupted current at R300 A 1
Maximum make/break capacity with R300 VA 28/28
CL-LDT…
Number of outputs 4
Contacts
Semiconductors
Rated voltage U
e
V DC 24
Permissible range V DC 20.4 to 28.8
Residual ripple % F 5
Supply current
On signal 0, typical/maximum mA 18/32
On signal 1, typical/maximum mA 24/44
Protection against polarity reversal
Attention!
If voltage is applied to the outputs when the polarity of the power supply
is reversed, this will result in a short circuit.
Yes
Potential isolation to the inputs, power supply, PC interface, memory
module, CL-NET network, CL-LINK
Yes
Rated current I
e
on signal 1, maximum A 0.5
Lamp load
Q1 to Q4 without R
V
W 5
