ABB CL Series User Manual

Technical data
403
1SVC 440 795 M1100
Making capacity, IEC 60947
AC-15 250 V AC, 3 A (600 ops/h) Switching
operations
300000
DC-13 L/R F 150 ms 24 V DC, 1 A (500 ops/h) Switching
operations
200000
Breaking capacity, IEC 60947
AC-15 250 V AC, 3 A (600 Ops/h) Switching
operations
300000
DC-13 L/R F 150 ms 24 V DC, 1 A (500 ops/h) Switching
operations
200000
Filament bulb load
1000 W at 230/240 V AC Switching
operations
25000
500 W at 115/120 V AC Switching
operations
25000
Fluorescent tube with ballast, 10 × 58 W at 230/240 V AC Switching
operations
25000
Conventional fluorescent tube, compensated,
1 × 58 W at 230/240 V AC
Switching
operations
25000
Conventional fluorescent tube, uncompensated,
10 × 58 W at 230/240 V AC
Switching
operations
25000
Operating frequency, relays
Mechanical operations Switching
operations
10 mill. (10
7
)
Mechanical switching frequency Hz 10
Resistive lamp load Hz 2
Inductive load Hz 0.5
CL-LDR…

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
