Screen overview
317
1SVC 440 795 M1100
Button editor All the buttons of the display system can be assigned
appropriate functions in the Button editor of the CL-SOFT,
thus overwriting the basic functions of the buttons. The
following steps are used to assign the buttons of the display
system:
• Select operable screen element,
• Display backlight,
• Screen change,
• Password logout,
• Set variable to fixed value,
• Increment variable,
• Decrement variable,
• Changeover relay.
Select operable screen element
If the program has a screen with a value entry, you can jump
to these value entry elements directly. The value entry
element is positioned in Entry mode so that you can change
the value directly.
Display backlight
You can increase or decrease the lighting of the backlight in
stages.
Screen change
This function enables you to change to other saved screens
during operation. If the operator is to be able to move
between several screens using a button function you must
assign a screen change button element to an operator
button in each of these screens.
