ABB CL Series User Manual

Visualization with the
display system
316
1SVC 440 795 M1100
Screen 2:
Screen 2 is virtually the same as screen 1 apart from an
extension in which the message text element can be
switched invisible via I1 (N/O contact bit logic). A N/C
contact bit logic would make the element visible.
Figure: 178: Switching message text invisible
Screen 3:
Screen 3 is virtually the same as screen 1 apart from an
extension in which the first message text element flashes
and the second is displayed inverted when I1 is actuated.
Figure: 179: Message text flashing and inverted
I1 not actuated I1 actuated
Invisible via
I1!
Message texts
Invisible via
I1!
Display
change via I1!
Message texts
Message texts
Display
change via I1!
are six
are six
