Working with contacts
and relays
137
1SVC 440 795 M1100
Saving circuit diagrams
X Press the ESC button to save a circuit diagram.
The menu on the left appears in the status line.
X Press OK. The entire program, circuit diagram and
function blocks will be saved.
After saving you will be in the CIRCUIT DIAGRAM menu.
Aborting circuit diagram entry
X If you want to exit without saving the circuit diagram,
press ESC.
X Use the cursor buttons ÍÚ to select the CANCEL menu.
X Press OK.
The circuit diagram is closed without saving.
Searching for contacts and coils
You can search for contacts and coils in the following way:
X Press ESC. Use the cursor buttons ÍÚ to select the
SEARCH menu.
X Press OK.
X Select the desired contact, coil and number with the Ú and
úí cursor buttons.
With function relays, select the function block, the number
and the coil.
X Confirm the search with the OK button.
The device will search for the first occurrence of the contact or
coil from the start of the search to the end of the circuit
diagram. If no contact or coil is found, the display system
circuit diagram editor will continue the search from the start of
the circuit diagram. If a contact or coil is found, the display
system editor automatically jumps to the respective field in the
circuit diagram.
I 01----I 02---
Q 01----HY01Q1k
Æ
SAVE æ
I 01----I 02---
Q 01----HY01Q1k
Æ
CANCEL æ
I 01----I 02---
Q 01----HY01Q1k
Æ
SEARCH æ
I 01----I 02---
Q 01----HY01Q1k
SEARCH I 01
I 01----I 02---
Q 01----HY01Q1k
L: 1 C:1 B:7140
