ABB CL Series User Manual

Function blocks
203
1SVC 440 795 M1100
Data function block
The data function block allows you to selectively save a
value. Setpoint values for the function block can be saved in
this manner.
Figure: 108: Display system circuit diagram with data function
block
Parameter display and parameter set for the data function
block:
Inputs
The function block input
>I1 can have the following
operands:
•Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: Terminal I7
– IA02: Terminal I8
– IA03: Terminal I11
– IA04: Terminal I12
• Analog output QA01
• Actual value …QV> of another function block
Output
The function block output QV> can have the following
operands:
• Markers MD, MW, MB
• Analog output QA01
GT01Q1---------------------------Ä DB16T
DB16Q1---------------------------S D 02EN
DB16 +
>I1
QV>
DB16 Data block function block number 16
+ Appears in the parameter display
>I1 Input value
QV> Actual value

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
