ABB CL Series User Manual

Function blocks
239
1SVC 440 795 M1100
Accuracy
The operating hours counter is accurate to the nearest
minute. If the enable coil signal is terminated within a
minute, the value for seconds is lost.
The value range of the operating hours counter is between 0
hours and 100 years.
PUT, send a value onto the network
The function block allows you to selectively send a 32 bit
value onto the network. The PUT function block provides
data on the CL-NET that another station indicates it requires
via the GET function block.
Figure: 125: Display system circuit diagram with PUT function
block
Parameter display and parameter set for the PUT function block:
Input
The function block input
>I1 can be assigned the following
operands:
•Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: Terminal I7
– IA02: Terminal I8
– IA03: Terminal I11
– IA04: Terminal I12
• Analog output QA01
• Actual value …QV> of another function block
T 01Q1---------------------------Ä PT16T
PT16Q1---------------------------Ä C 01C
PT01 11 -
>I1
PT01 PUT function block (places a value onto the network),
number 11
- Does not appear in the parameter display
>I1 Setpoint value which is put onto the CL-NET network
