Display system settings
358
1SVC 440 795 M1100
Startup behaviour The startup behaviour is an important aid during the
commissioning phase. The circuit diagram which the display
system contains is not as yet fully wired up or the system or
machine is in a state which the display system is not
permitted to control. The outputs should not be controlled
when the display system is switched on.
Setting the startup behaviour
Requirement: the display system must contain a valid circuit
diagram.
X Switch to the System menu.
Specify the operating mode which the display system must
use when the supply voltage is applied.
Activating RUN mode
If the display system displays
RUN MODE å, this means
that the display system will start in Run mode when the
supply voltage is applied.
X Otherwise select RUN MODE and press OK.
RUN mode is activated.
X Press ESC to return to the status display.
Deactivating RUN mode
X Select RUN MODE å and press OK.
The RUN mode function is deactivated.
h
The display system without a display can only be started in
RUN mode.
h
If the display system is password-protected, the System
menu can only be accessed after the display system has
first been “unlocked” (a section “Unlocking the display
system”, from page 347).
DEBOUNCE å Æ
P BUTTONS
RUN MODE å
CARD MODE æ
DEBOUNCE å Æ
P BUTTONS
RUN MODE
CARD MODE æ
