Configuring the interface
for the COM-LINK mode
99
1SVC 440 795 M1100
X Go to the display system device that is the active station
running the serial interface (POW-Side).
Setting up the COM-LINK
X Simultaneously press the DEL and ALT buttons with the
status display active.
The System menu appears
Select the CONFIGURATOR menu option.
X Press the OK button.
Select the COM… menu option.
X Press the Ú button.
X Press the OK button.
The menu BAUDRATE: 9600B will appear. The two baud
rates are for 9600 or 19200 baud. Select the baud rate that
your connection will support. Baud rate selection.
h
The following steps are only possible in STOP mode.
Caution!
The display system device can either run as a station on
the CL-NET or as a station in a COM-LINK connection. Do
not switch the display system as CL-NET station over to
COM-LINK. If this is done on CL-NET in RUN mode, the
entire CL-NET network will be deactivated. No more data
will be exchanged.
Solution:
X Deactivate the COM-LINK.
X Re-enter the CL-NET address.
X Switch the power supply off and then on again.
X Reconfigure the CL-NET on station 1.
SECURITY
SYSTEM...
MENU LANGUAGE
CONFIGURATOR
NET..
COM...
LINK...
BAUDRATE: 9600B
COM-LINK
REMOTE MARKER...
