Commissioning
100
1SVC 440 795 M1100
X Press the OK button.
Select 19200 baud as the baud rate.
X Press the Í or Ú button.
X Confirm with the OK button.
Switch on the COM connection.
X Press the Ú button.
X Press the OK button.
The tick next to the COM-LINK menu indicates that
COM-LINK has been selected.
No tick means that COM-LINK has not been selected.
X Select the REMOTE MARKER menu item.
The following selection will only be displayed if the
COM-LINK menu item has been ticked.
X Press the OK button.
The data is present in the second station, the remote station.
h
Select 19200 baud as the baud rate. Badly laid cables may
give rise to electromagnetic interference. Select
9600 baud as a solution. If this is not satisfactory, the
connection cable must be laid in a different location.
BAUDRATE:19200B
COM-LINK
REMOTE MARKER...
h
The COM-LINK must only be switched at the active
station. Two devices with COM-LINK å switched on
cannot communicate with each other.
BAUDRATE:19200B
COM-LINK å
REMOTE MARKER...
h
The following applies to the active station:
If you wish to run data transfers between the two devices
in both directions, you must select the marker range on
the active station.
BAUDRATE:19200B
COM-LINK å
REMOTE MARKER...
READ:
1MD00 Ç 1MD00
WRITE:
1MD00 Ç 1MD00
