ABB CL Series User Manual

Operating the display system
19
1SVC 440 795 M1100
Status display for local expansion
Advanced status display
Display system LED display
The display system is provided with two LEDs on the rear of
the CL-LDC.L… display base module. These indicate the
status of the power supply (POW) and the RUN or STOP
operating mode (a fig. 1, page 14).
Inputs AC expansion ok/P buttons
Expansion device or Weekday/Date
Weekday/Time
Outputs
On: 1, 2, 3, 4/Off:…
RS = Expansion functioning correctly
R 1.........12
RS AC P-
MO 10:42
S 1......8 STOP
Retention/debounce
CL-NET station
AC expansion ok/P buttons
Startup behaviour
RE
: Retention switched on
I
: Debounce switched on
NT1
: CL-NET station with station address
COM
COM connection active
AC
: AC expansion functioning correctly
DC
: DC expansion functioning correctly
GW
: Bus coupling module detected
GW flashing: Only CL-LEC.CI000 detected. I/O expansion not detected.
ST
: When the power supply is switched on, the display system switches to STOP mode
I 12...6.89..12
RE I NT1 AC P-
MO 14:42 T
Q 12345678 RUN
