Screen overview
315
1SVC 440 795 M1100
Example program 5 – Several message texts in one
text element
The program consists of three screens that you can select via
cursor buttons
Í and Ú. The screen change was defined in
the button editor (a section “Button editor”, page 317).
The program is used to display several messages in one
message text element. It also illustrates the function of the
Visibility tab and the Display change tab. The pulse
generator T01 activates the counter C01. This counts up to
seven and then resets itself. This produces a continuous loop
in which the individual messages are activated.
Standard path: C:\Program files\CL-SOFT\Samples\
Program:
Messagetext_Prog_05.e60
Screen 1:
The first screen contains a message text element with six
messages.
• Status value 1: Message text “These”
• Status value 2: Message text “are six”,
• Status value 3: Message text “message texts”
• Status value 4: Message text “in one”
• Status value 5: Message text “message text”
• Status value 6: Message text “element!”.
It can be seen that the messages can be moved within the
entry field.
