Visualization with the
display system
314
1SVC 440 795 M1100
Screen 1:
The first screen shows four bit message text elements. These
are triggered in succession via the outputs Q1 to Q4 and
appear in the display.
Screen 2:
The second screen contains a message text element with
two message texts.
Status value 1: Message text “Error”
Status value 2 and 3: Default text “default”
Status value 4: Message text “RESTART”
If the status value of CO1 is 1, the message text “Error” is
displayed flashing since the function block parameter FB is
set in the Display change area of the Display change tab. The
function block parameter switches if the SL value (lower set
value) of the counter is reached (aCL-SOFT Function block
editor counter C01).
Figure: 177: Message text with default text
Start Machine 1
Start Machine 2
Start Machine 3
Start Machine 4
Error default:
RESTART
