ABB CL Series User Manual

Introduction to COM-LINK
337
1SVC 440 795 M1100
Data accesses via COM-LINK
The following data access operations are possible from the
active station to the remote station:
Write/read accesses in the marker range
Active station, read Remote station
Inputs 1I01 to 1I16
I01 to I16
Inputs of local expansion unit 1R1 to 1R16
R01 to R16
Outputs 1Q01 to 1Q08
Q01 to Q08
Outputs of local expansion unit 1S01 to 1S08 S01 to S08
Diagnostics bits of CL-NET 1ID01 to 1ID08
ID01 to ID08
Analog inputs 1IA01 to 1IA04
IA01 to IA04
Analog output 1QA01
QA01
Active station Remote station
1 MD01
MD01
1 MW01 1MW02 MW01 MW02
1 MB01 1MB02 1MB03 1MB04 MB01 MB02 MB03 MB04
1 M01 to 1 M32
M01 to M32
1 MD02 MD02
1 MW03 1MW04 MW03 MW04
1 MB05 1 MB06 1 MB07 1 MB08 MB05 MB06 MB07 MB08
1 M33 to 1 M64 M33 to M64
1 MD03 MD03
1 MW05 1 MW06 MW05 MW06
1 MB09 1 MB10 1 MB11 1 MB12 MB09 MB10 MB11 MB12
1 M65 to 1 M96 M65 to M96
1 MD04
MD04
1 MW07 1 MW08 MW07 MW08
..... ....
....
1 MD20 MD20
1 MW39 1 MW40 MW39 MW40
1 MB77 1 MB78 1 MB79 1 MB80 MB77 MB78 MB79 MB80
