ABB CL Series User Manual

Appendix
414
1SVC 440 795 M1100
CF
40 4
CH 52 4
CI 52 4
CP 32 4
DC 96 4
DB 36 4
FT 56 4
GT 28
HW 68 4 (per channel)
HY
68 4 (per channel)
LS 64 4
MR 20
NC 32 4
OT 36 4
PT 36 4
PW 48 4
SC 20
ST 24 4
T 48 4
VC 40 4
: – –
Space requirement per rung/
function block
Space requirement per constant
at function block input
Byte Byte

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
