ABB CL Series User Manual

Function blocks
157
1SVC 440 795 M1100
Arithmetic function block modes
Value range
The function block operates in the integer range from
–2147483648 to +2147483647.
Behaviour when value range is exceeded
• The function block sets the switching contact AR..CY to
status 1.
• The function block retains the value of the last valid
operation. The value is zero when it is first called.
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Contacts
AR01CY to AR32CY: CARRY overflow bit, value on function
block output greater than or less than the value range.
AR01ZE to AR32ZE: zero bit ZERO, value at the function
block output equals zero
Coils
The arithmetic function block does not have any coils.
Memory requirement of the arithmetic function block
The arithmetic function block requires 40 bytes of memory
plus 4 bytes per constant on the function block inputs.
Parameter Function
ADD Addition of summand value >I1 plus summand >I2
SUB Subtraction of minuend >I1 minus subtrahend >I2
MUL Multiplication of factor >I1 by factor >I2
DIV Division of dividend >I1 by divisor >I2
