ABB CL Series User Manual

Wiring with the display system
162
1SVC 440 795 M1100
The comparison result of the function block BC01 is:
BC01EQ = 1, the data block ranges have the same content.
Example:
Comparison of marker blocks, definition of a marker range
with offset
Two marker blocks are to be compared. Block 1 starts at
MB15, Block 2 starts at MB65. Each block is 4 bytes long.
Parameters of BC01 function block:
Comparison range 1:
>I1 MB15
Comparison range 2:>I2 64
Number of bytes: >NO 4
Marker MB01: 1
Comparison
range 1
Value of marker
range 1 (decimal)
Comparison
range 2
Value of marker
range 2 (decimal)
MB10 39 MB40 39
MB11 56 MB41 56
MB12 88 MB42 88
MB13 57 MB43 57
MB14 123 MB44 123
MB15 55 MB45 55
MB16 134 MB46 134
MB17 49 MB47 49
MB18 194 MB48 194
MB19 213 MB49 213
h
Comparison range 2: Constant 64:
MB01 plus offset: 1 + 64 = 65 r MB65.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
