ABB CL Series User Manual

Wiring with the display system
174
1SVC 440 795 M1100
After a rising edge from 0 to 1 at coil BT01T_ the content of
MB15 to MB18 is copied to the marker bytes MB65 to MB68.
Example:
Copying of marker blocks, definition of a marker range in a
different format.
The value of marker byte MD60 to MD62 is to be copied to
MW40 to MW45.
Parameters of BT01 function block:
Source range:
>I1 MD60
Destination range:>I2 MW40
Number of bytes: >NO 12
Source range Value of source
marker range
(decimal)
Target range Value of destination
marker range
(decimal)
MB15 68 MB65 68
MB16
189 MB66 189
MB17 203 MB67 203
MB18 3MB683
h
The transfer is in byte format. 12 bytes are to be copied.
The range MD60 to MD62 is 12 bytes. This is copied to the
range MW40 to MW45.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
