ABB CL Series User Manual

Wiring with the display system
182
1SVC 440 795 M1100
Inputs
The function block inputs
>SH, >SL and >SV can have
the following operands:
•Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: Terminal I7
– IA02: Terminal I8
– IA03: Terminal I11
– IA04: Terminal I12
• Analog output QA01
• Actual value …QV> of another function block
Actual value …QV>
The actual value …QV> can be assigned the following
operands:
• Markers MD, MW, MB
• Analog output QA01
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Contacts
• C 01OF to C 32OF: Actual value f upper setpoint
• C 01FB to C 32FB: Actual value F Lower setpoint value
• C 01ZE to C 32ZE: Actual value = Zero
• C 01CY to C 32CY: Value range exceeded
