ABB CL Series User Manual

Wiring with the display system
194
1SVC 440 795 M1100
When the display system is restarted in RUN mode, the counter
relay continues with the retentively stored actual value.
Function of the high-speed counter function block
Figure: 104: Signal diagram of high-speed counter
1: Counter input I1 to I4
2: Upper setpoint value
>SH
3: Preset actual value >SV
4: Lower setpoint value >SL
1
2
......... .........
3
4
6
7
8
9
10
11
12
ABCD E F
5

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
