Function blocks
199
1SVC 440 795 M1100
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Contacts
• CI01OF to CI02OF: Actual value f Upper setpoint
• CI01FB to CI02FB: Actual value F Lower setpoint
• CI01ZE to CI02ZE: Actual value = Zero
• CI01CY to CI02CY: Value range exceeded
Coils
• CI01EN to CI02EN: Counter enable
• CI01RE to CI02RE: Reset actual value to zero
• CI01SE to CI02SE: Accept preset actual value with rising
edge.
Memory requirement of the counter relay
The high-speed counter function block requires 52 bytes of
memory plus 4 bytes per constant on the function block
inputs.
Retention
High-speed counter relays can be operated with retentive
actual values. The number of retentive counter relays can be
selected in the SYSTEM r RETENTION menu.
If a counter relay is retentive, the actual value is retained
when the operating mode changes from RUN to STOP as
well as when the power supply is switched off.
When the display system is restarted in RUN mode, the
counter relay continues with the retentively stored actual
value.
