ABB CL Series User Manual

Function blocks
209
1SVC 440 795 M1100
PID controller equation:
Y(t) = Y
P
(t) + Y
I
(t) + Y
D
(t)
Y(t) = Calculated manipulated variable with scan time t
Y
P
(t)= Value of the proportional component of the manipulated
variable with scan time t
Y
I
(t)= Value of the integral component of the manipulated variable
with scan time t
Y
D
(t)= Value of the differential component of the manipulated
variable with scan time t
The proportional component in the PID controller
The proportional component Y
P
is the product of the gain
(K
p
) and the control difference (e). The control difference is
the difference between the setpoint (X
s
) and the actual value
(X
i
) at a specified scan time. The equation used by the device
for the proportional component is as follows:
Y
P
(t)= K
p
x [X
s
(t) – X
i
(t)]
K
p
= Proportional gain
X
s
(t) = Setpoint with scan time t
X
i
(t) = Actual value with scan time t
The integral component in the PID controller
The integral component Y
I
is proportional to the sum of the
control difference over time. The equation used by the device
for the integral component is as follows:
Y
I
(t) = K
p
x T
c
/T
n
x [X
s
(t) – X
i
(t)] + Y
I
(t–1)
K
p
= Proportional gain
T
c
= Scan time
T
n
= Integration time (also known as reset time)
X
s
(t) = Setpoint with scan time t
X
i
(t) = Actual value with scan time t
Y
I
(t–1)= Value of the integral component of the manipulated
variable with scan time t –1

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
