ABB CL Series User Manual

Wiring with the display system
212
1SVC 440 795 M1100
Inputs
The function block inputs
>I1, >I2 and >KP can have
the following operands:
•Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: Terminal I7
– IA02: Terminal I8
– IA03: Terminal I11
– IA04: Terminal I12
• Analog output QA01
• Actual value …QV> of another function block
Output
The function block output QV> can have the following
operands:
• Markers MD, MW, MB
• Analog output QA01
Value range for inputs and outputs
Example:
Value range Resolution/unit
>I1 Input value of the function block –32768 to +32767
>TG Recovery time T
g
0 to 65535 in 100/ms
>KP Proportional gain K
p
0 to 65535 in --/%
QV> Output value –32768 to +32767
Value at input Value processed
in the function
block.
>TG Recovery time T
g
250 25 s
>KP Proportional gain K
p
1500 15

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
