ABB CL Series User Manual

Function blocks
221
1SVC 440 795 M1100
Wiring of a year time switch
A year time switch is integrated into the circuit diagram as a
contact.
Figure: 118: Display system circuit diagram with year time
switch
Parameter display and parameter set for the year time switch
HY:
Channels
4 channels are available per time switch, channels A, B, C
and D. These channels all act on the contact of the year time
switch.
Date
Day.Month.Year: DD.MM. YY
Example: 11.11.02
On and off times
ON: Switch on time
OFF: Switch off time
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
HY30Q1---------------------------Ä S 08
HY30 B +
>ON
>OFF
HY30 Year time switch function block number 30
B Time switch channel B
+ Appears in the parameter display
>ON Switch on time
>OFF Switch off time
h
The switch on year must not be later than the switch off
year. Otherwise the year time switch will not function.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
