ABB CL Series User Manual

Function blocks
223
1SVC 440 795 M1100
Example 2
Month range selection
The year time switch HY01 should switch on at 00:00 on
March 1 and remain on until 23:59 on September 30.
Example 3
Day range selection
The year time switch HY01 should switch on at 00:00
on the 1st of each month and remain on until 23:59 on
the 28th of each month.
Example 4
“Holiday” selection
The year time switch HY01 should switch on at 00:00
on 25.12. and remain on until 23:59 on the 26.12.
“Christmas program”
Example 5
Time range selection
The year time switch HY01 should switch on at 00:00
on 01.05. each year and remain on until 23:59 on the
31.10 of each year.
HY01 A +
>ON __.03.--
>OFF --.09.--
HY01 A +
>ON 01.--.--
>OFF 28.--.--
HY01 A +
>ON 25.12.--
>OFF 26.12.--
HY01 A +
>ON 01.05.--
>OFF --.--.--
HY01 B +
>ON --.--.--
>OFF 31.10.--
