Wiring with the display system
230
1SVC 440 795 M1100
Power flow display
Jumped sections are indicated by the coils in the power flow
display.
All coils after the jump coil are shown with the symbol of the
jump coil.
Example
A selector switch allows two different sequences to be set.
Sequence 1: Switch on motor 1 immediately.
Sequence 2: Switch on guard 2, wait time, then switch on
motor 1.
Contacts and relays used:
•I1 sequence 1
•I2 sequence 2
I3 guard 2 moved out
I12 motor-protective circuit-breaker switched on
Q1 motor 1
•Q2 guard 2
T01 wait time 30.00 s, on-time
D01 text “Motor-protective circuit-breaker tripped”
