ABB CL Series User Manual

Wiring with the display system
246
1SVC 440 795 M1100
Inputs
The function block input
>I1 can have the following
operands:
•Constants
• Markers MD, MW, MB
• Analog inputs IA01 to IA04
– IA01: Terminal I7
– IA02: Terminal I8
– IA03: Terminal I11
– IA04: Terminal I12
• Analog output QA01
• Actual value …QV> of another function block
Displaying the parameter set in the PARAMETERS
menu
• + Access enabled
• – Access disabled
Coils
ST01EN, enable coil.
Memory requirement of the function block
The set cycle time function block requires 24 bytes of
memory plus 4 bytes per constant on the function block
input.
Function of the set cycle time function block
The function block is used to define a fixed cycle time.
Actual cycle time is less than the set cycle time:
If the maximum cycle time present is less than the set cycle
time, the set cycle time is constant.
Actual cycle time is greater than the set cycle time:
If the maximum cycle time present is greater than the set
cycle time, the set cycle time has no effect.
h
The function block must be enabled so that it can work.
Coil ST01EN is active. If coil ST01EN is not active, the
entire function block is deactivated and reset.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
