ABB CL Series User Manual

Function blocks
263
1SVC 440 795 M1100
Figure: 143: Wiring with display system
Figure: 144: Display system wiring and circuit diagram
H1
L01–
S1 S2
L01+
L01–
F1
I 01----I 02- --Ä Q 01
+24V 0V 0V
I1 I3I2
Q1
12
DEL
ESC
ALT
OK
*
I 05---------------------------Ä C 01C
I 06---------------------------Ä C 01RE
C 01---------------------------Ä T 01EN
T 01Q1-------------------------Ä Q 01

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
