Wiring with the display system
266
1SVC 440 795 M1100
Doubling the flashing frequency:
X Select the power flow display T 01 and change the
constant of the setpoint time to
001.000.
When you press OK, the warning light will flash at twice the
frequency.
On the display
EN indicates that the enable coil is actuated.
Setpoint value settings with constants can be modified via
the PARAMETERS menu.
T 01 Ü S +
>I1 001.000
>I2
QV> 0.550
.. EN ..
h
The actual value is only shown in RUN mode. Call up the
parameter display for this via the power flow display or
PARAMETERS menu.

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
