ABB CL Series User Manual

Display system
24
1SVC 440 795 M1100
MB -- -> MB -- Æ
C -- -> C --
CH -- -> CH --
B: 200 æ
CI -- -> CI --
DB -- -> DB --
T -- -> T --
DEBOUNCE å Æ
P BUTTONS
RUN MODE
CARD MODE æ
TERMINAL MODE
DISPLAY...
RETENTION...
INFORMATION...
System menu
SECURITY
SYSTEM...
MENU LANGUAGE...
CONFIGURATOR
Retention only in STOP
mode
DEBOUNCE å Æ
P BUTTONS å
RUN MODE å
CARD MODE å æ
TERMINAL MODE å
DISPLAY...
RETENTION...
INFORMATION...
DEBOUNCE å
P BUTTONS
RUN MODE
CARD MODE Æ
TERMINAL MODE
DISPLAY...
RETENTION æ
INFORMATION...
DEBOUNCE å
P BUTTONS
RUN MODE Æ
CARD MODE
TERMINAL MODE
DISPLAY æ
RETENTION...
INFORMATION...
CONTRAST: 0
LIGHTING: 75%
DEBOUNCE å
P BUTTONS
RUN MODE
CARD MODE
TERMINAL MODE Æ
DISPLAY...
RETENTION...
INFORMATION... æ
DC TCA LCD NET
OS : 1.11.111
CRC: 63163
Æ

ABB CL Series Specifications

General

Manufacturer	ABB
Rated Control Supply Voltage (Us)	24 V DC
Mounting	DIN Rail
Category	Relays
Contact Configuration	SPDT
Coil Voltage	24 V DC
Operating Temperature	-40°C to +70°C
Electrical Life	100 Thousand Cycles
Output	Relay
