ABB CL Series User Manual

Visualization with the
display system
282
1SVC 440 795 M1100
Screen 5:
Format: WD DD.MM.YY
Display of weekday and date in normal size.
Screen 6:
Format: HH:MM
Display of hour and minute, single display format.
Screen 7:
Display of different formats in one screen. Display in normal
size.
Screen 8:
Display invisible, if I1 actuated. (N/O contact bit logic!)
Example program 2 – Different display types with
automatic screen change
This program is a copy of the program
D
ate_a_Time_Prog_01.e60 except that the screen
change is automatic. The program consists of eight screens
that are triggered in succession by counter C01. The pulses
for activating the screens are supplied by timing relay T01.
This produces counter values 0 to 9. Counter value 1
activates screen 1, counter value 2 screen 2 etc. The counter
resets itself when the upper limit value SH = 9. This produces
a continuous loop. “German” is the language setting in all
eight screens.
Standard path: C:\Program files\CL-SOFT\Samples\
Program:
Date_a_Time_Prog_02.e60
Example program 3 – Different country settings
The program consists of 11 screens that are triggered
automatically by counter C01. The pulses for activating the
screens are supplied by timing relay T01. This produces
counter values 0 to 12. Counter value 1 activates screen 1,
counter value 2 screen 2 etc. The counter resets itself when
the upper limit value SH = 12. This produces a continuous
loop. Each screen contains a different country setting.
However the same format WD DD MM YY is shown.
WE 01.10.03
Invisible
via I1!
01.10.2003
