Visualization with the
display system
284
1SVC 440 795 M1100
Programming in CL-SOFT:
X Drag the Bitmap element onto the screen with the left
mouse button depressed.
This will open the Picture File Selection dialog.
For optimum display of the graphic file select one of the
three conversion processes provided in the Conversion Type
area. The preview shows the selected bitmap and the
converted result. CL-SOFT always creates the best possible
black and white bitmap graphic for showing on the
monochrome display screen. You can use CL-SOFT here for
support in optimising the graphic file.
X Position the cursor over the screen element and move it to
the required position whilst holding down the left mouse
button.
The height and width of the element frame can be scaled as
required and is adjusted accordingly by enlarging or
reducing the screen element frame horizontally or
diagonally. This is done by dragging a selection square of the
element frame with the mouse button depressed. The side
ratios of the original graphic are retained when you use the
diagonal zoom function.
“Display” tab
The Display tab offers the following display options for the
bitmap:
• Bitmap flashing (via associated variable),
• Background transparent or covered,
• Invert bitmap display
“Visibility” tab
The Visibility tab makes it possible to switch the element to
invisible via an associated variable.
