ABB CL Series User Manual

Screen overview
291
1SVC 440 795 M1100
Screen 1:
The screen shows six simple output formats of the numerical
values and provides an overview of the properties of the
Number range/format tab. The first screen shows six
numerical values. These are all associated via the on-delayed
timing relay T04 (Associated variables tab) for which a time
range of 4 seconds is set. The actual value of the timing relay
is provided at its QV output (FB parameter) and is then
displayed in the appropriate number format. The variable
type of the association is of type DWord.
Table 11: Numerical values and output formats
Figure: 158: Output formats
Left column Right column
Numerical value 1
• Value range 0 to 50 000
• Unit: None
• Scaling Range: None
• Always Show Sign: No
Numerical value 1
• Value range: 0 to 4 000
• Unit: None
• Scaling Range: 0 to 4
• Decimal Places: 0
• Always Show Sign: No
Numerical value 2
• Value range 0 to 50 000
• Unit: ms
• Scaling Range: None
• Always Show Sign: No
Numerical value 2
• Value range: 0 to 4 000
• Unit: s
• Scaling Range: 0 to 4
• Decimal places: 1
• Always Show Sign: No
Numerical value 3
• Value range 0 to 50 000
• Unit: ms
• Scaling Range: None
• Always Show Sign: Yes
Numerical value 3
• Value range: 0 to 4 000
• Unit: s
• Scaling Range: 0 to 4
• Decimal Places: 2
• Always Show Sign: Yes
Timer 4
1873 2
1873ms 1.9s
+1873ms +1.87s
